Waterproof Plug D SUB Male Plug Connector Plastic IP68 Communication Cable Socket

Waterproof Plug D SUB Male Plug Connector Plastic IP68 Communication Cable Socket

    • Waterproof Plug D SUB Male Plug Connector Plastic IP68 Communication Cable Socket
    • Waterproof Plug D SUB Male Plug Connector Plastic IP68 Communication Cable Socket
    • Waterproof Plug D SUB Male Plug Connector Plastic IP68 Communication Cable Socket
    • Waterproof Plug D SUB Male Plug Connector Plastic IP68 Communication Cable Socket
  • Waterproof Plug D SUB Male Plug Connector Plastic IP68 Communication Cable Socket

    Product Details:

    Place of Origin: China
    Brand Name: BEDE
    Certification: UL CE ROHS
    Model Number: DB 9Pin

    Payment & Shipping Terms:

    Minimum Order Quantity: 100
    Price: $0.99
    Packaging Details: 1000 pcs in a carton, size 480*410*410mm, G.W. 25KG.
    Delivery Time: 2 days for retail, 20 days for wholesale
    Payment Terms: Western Union , T/T ,Papay
    Supply Ability: 20000/week
    Contact Now
    Detailed Product Description
    Model Number:: BEDE-AISG-DB9 Type: Plastic Connector
    Protection Level: IP 67/68 Function: Waterproof
    Material: PA66 UL94V-0 Colour: Black
    High Light:

    control cable assembly

    ,

    control cable connectors

       AISG Cable Waterproof Plug D-SUB Connector IP68 Waterproof Grade Communication Cable Socket

    Description
    1,Waterproof rating IP68/67
    2,Comply with RoHS and REACH standards
    3,Rated voltage: 300V
    4,Insulation resistance: ≥1000MΩ
    5,Rated current: 5A
    6,Contact resistance: ≤10mΩ
    7,Ambient temperature: -25°C~ + 70°C
    8,Contact: brass plated
    9,Coupling nut/screw: brass nickel plated

    Click To Download DB-TDS.pdf

    Waterproof Plug D SUB Male Plug Connector Plastic IP68 Communication Cable Socket 0

    Model specification

    Name Factory Model Standards
    DB9 Connector BEDE BEDE-AISG-DB9 RoHS



    Parameter

    Name Material Plating
    Plastic connector PA66 UL94V-0 /
    Size 4.1cm*2.2cm*25cm /
    Pinhole brass 1.27um Ni bottom, gold plated contact 0.02-0.03um, fogging in the tail area Tin 2.5um

    installation Screw
    Size 30.8(A)*25(B)*12.5(C)*2.29(D)
    Pins No. 15
    Button /
    Operating temperature  -55℃~125℃
    Rated voltage /
    Rated current  3A
    Withstand voltage  1000VAC,60s,1mA
    Insulation resistance ≥5000MΩ
    Contact resistance ≤30mΩ
    Contact form  welding
    Lifetime 500 cycles
    Storage conditions Normal temperature and humidity, no corrosive gas environment
    Storage time 5 years
